S -18.3 to 50.0 ±6.1° -1.0 to 122.0 ±10.9°
50.0 to 300.0 ±3.7° 122.0 to 572.0 ±6.6°
300.0 to 600.0 ±2.6° 572.0 to 1112.0 ±4.7°
600.0 to 1767.8 ±2.3° 1112.0 to 3214.0 ±4.2°
B 315.6 to 600.0 ±7.9° 600.0 to 1122.0 ±14.2°
600.0 to 1050.0 ±4.0° 1122.0 to 1922.0 ±7.3°
1050.0 to 1400.0 ±2.5° 1922.0 to 2552.0 ±4.6°
1400.0 to 1820.0 ±2.1° 2552.0 to 3308.0 ±3.8°
N -230.0 to 0.0 ±4.2° -382.0 to 32.0 ±7.5°
0.0 to 450.0 ±0.9° 32.0 to 842.0 ±1.7°
450.0 to 1150.0 ±0.6° 842.0 to 2102.0 ±1.1°
1150.0 to 1300.0 ±0.7° 2102.0 to 2372.0 ±1.2°
G
(W)
100.0 to 300.0 ±4.5° 212.0 to 572.0 ±8.2°
300.0 to 650.0 ±2.1° 572.0 to 1202.0 ±3.7°
650.0 to 1800.0 ±1.3° 1202.0 to 3272.0 ±2.4°
1800.0 to 2320.0 ±1.9° 3272.0 to 4208.0 ±3.5°
C
(W5)
-1.1 to 200.0 ±1.8° 30.0 to 392.0 ±3.2°
200.0 to 1350.0 ±1.4° 392.0 to 2462.0 ±2.6°
1350.0 to 2000.0 ±1.9° 1742.0 to 3632.0 ±3.4°
2000.0 to 2320.0 ±2.6° 3632.0 to 4208.0 ±4.7°
T/C Degrees C
Range
°C Degrees F
Range
°F
Thermocouple Ranges & Accuracies
Table based on Accuracy:
≤ ± (0.03 % of 80 mV)
Note: Doesn’t include cold junction error of ±0.1°C
