PILLAR MACHINE H49 - Page 13

PROGRAMMING
Connued
Horizontal Standard Drill Operaon:
Insert the Horizontal Standard Drill Operaon.
Highlight the operaon, then press edit.
Choose what spindle to use to perform the operaon, standard
HPJ uses H1
Drill hole opts to drill a hole at the described locaon.
Insert dowel will drive a dowel into the described locaon.
The X Posion is located from the side fence to the center of the
hole. Zone 2 and 4 will mirror the operaon.
The Close Buon is used to accept the osets entered.
Repeat funcons can be used to standardize, or simplify
your recipe library. Instead of creang unique programs for
each part, you can describe paerns to trigger o of spe-
cic part size condions. Greater than, less than, equal to,
etc.
