Pilot Communications PMAC211 User Manual

20
Parameter setting range:
Item Data range Illustration
Password 1 Initial value is 1
Communication
address
1~247 Initial value is 1
Communication
baud rate
4800bps or 9600bps
Initial value is 9600bps
0: 4800bps;
1: 9600bps;
Rated current 50~600A Default 100A
Voltage upper
limit
0~280.0V ， 0 means
alarm close
Alarm action: when the value larger
then setting value
Alarm return: 5s later after the action
condition disappear
Voltage bottom
limit
0~220.0V ， 0 means
alarm close
Alarm action: when the value smaller
then setting value
Alarm return: 5s later after the action
condition disappear
Current upper
limit
0~800.0A ， 0 means
alarm close
Alarm action: when the value larger
then setting value
Alarm return: 5s later after the action
condition disappear
