17
Tail Wheel Installation
Rudder Assembly
1. Draw a center line with a pencil
as shown
3. Drill hole 1mm bit and mount
spring on the buttom of rudder with
self-tapping screws as shown.Cut
away excess wire. Ensure spring
have pulled tightly
2. Mount self-tapping screws on the
tail wheel mounting block with the
bracket taped on place
To Next Page
