Throttle servo Installation
A drop of gule on nut
5. Finish the servo installation with
mounting screws
Throttle Servo Installation
1. Install the engine throttle arm
witn a little Blue Loctite. Measure
and cut the extra wire .Then bend
to a sharp of “z” as shown. Mount
the throttle pushrod to engine
2. Determine where the throttle servo
mounting tray is going to be mounted
on the engine box to get the straight
and precise throttle linkage connection.
Then make a mark and epoxy the tray
in place .Finally secure with self-
tapping screws
