Servo Installation
1. Mount servo with mounting
screws and face the brand toward
the rudder.Drill holes with 1mm bit
2. Tape the rudder panel to top of
the vertical fin in the neutral position
to make it straight
The rudder cables and couplers have
been installed as shown
3. Attach the pre-installed boll link
to the rudder horn and not tighten
the locking nut
Rudder Servo Assembly
To Next Page
