21
Servo Unit
Wing Servo Assembly
Minimum Request Servo:
Servo Arm Installation
1. Turn on your transmitter and
plug the servo into receiver. Ensure
every channel is neutral
2. Ensure the servo arm is 90
degrees with servo as shown. Then
mark and drill holes with 2mm bit
3. Mounting screws and nuts
180 in.zo / Metal Gear / Digital
A drop of fast
cured gule here
Pre fasten the arm
with drops of fast
cured gule on edge
To Next Page
