24
3. Tape the lead to pull-string
tightly. In order to ensure the servo
wire can be pulled out without
hanging up inside wing
4. Then put the extention lead
through the root of wing
5. Install servo with mounting
screws. Face the brand toward the
trailing edge of the wing. Use 1mm
bit to drill the mounting holes
Wing Servo Assembly
2. Lock the connector with the
provided safety clip against vibration
and loosened tension as shown
To Next Page
