29
7. Thread the coupler in 2 – 4 mm.
Ensure the same length of cables
and tension
9. Remove the ball links from
rudder horn and install the servo
arm ball links with bolts and nuts
10. Turn off the radio now. Reinstall
the ball link (Don’t pull strongly to
hurt the rudder or back to step 7 for
readjustment )you can find a helper
and do that at certain deflection with
supporting the bottom of the rudder.
Rudder Servo Assembly
8. Shrink the heat shrinking tube on
the brass tube
2-4mm
