- 10 -
Abmessungen in mm (")
Anschlussbelegung
Connector pin assignment
Dimensions in mm (")
Affectation des raccords
Dimensions en mm (")
GB
D
F
GB
D
F
Gehäuse mit steckbaren Schraubklemmen/
Housing with plug-in screw terminals/
Boîtier avec borniers débrochables à vis
Gehäuse mit steckbaren Käfigzugfederklemmen/
Housing with plug-in cage clamp terminals/
Boîtier avec borniers débrochables à ressort
1
2
3
75 (2.95")
90,5 (3.56")
121 (4.76")
22,5
(0.88")
87 (3.42")
75 (2.95")
94 (3.70")
121 (4.76")
22,5
(0.88")
87 (3.42")
