Pima FORCE Series Installation Guide

1: Introduction
PIMA Electronic Systems 7
1.3 Technical specifications
 AC power input: 11-18V. FORCE Lite: 14.5V
 Backup battery input: 13.8VDC
 Relay: 1A max.
 On/Off and Alarm outputs (minus, open drain): 10A max., external power: +25V max.
 Output current
 Max: +13.8VDC, 1.1A. FORCE Lite/32: +13.8VDC, 750mA
 Idle: 50mA
 EOL resistors: programmable
 Operating temperature: -10 to +50 °C
 Humidity (max.): 93% R.H., non-condensing
1.4 Ordering information
Product
P/N
FORCE
8350012
FORCE Lite
8350056
FORCE 32
8350212
FORCE 32C
8350303
1.4.1 Peripherals
Product
Description
P/N
Hardwired
KLA500
Keypad arming station (wired)
8415020
KLR500
Rubber key, LCD screen keypad
8415001
KLT500
Touch key, LCD screen keypad
8415010
ZEL508
Local 8-zone expander. The card is installed beside the
control panel and is connected using a special 4-wire cable.
8330011
ZEX508
8-zone expander with one relay output
8500026
ZEP608
8-zone expander with PS-2 1.2A power supply, mounted in a
metal case.
8290011
ZEX516
16-zone expander with two relay outputs
8500027
ZEP716
16-zone expander with 13.8V to 4.2A power supply,
mounted in a metal case.
8290013
OEX508
8-relay outputs expander
8500028
Radio and cellular
TRV-100
TRU-100
Long-range radio transmitters
 TRV-100 Low: 8200011
 TRV-100 High: 8200010
 TRU-100 Low: 8300005
 TRU-100 Medium: 8300009
 TRU-100 High: 8300006
 VHF Antenna 42cm: 6110003
 VHF Antenna 51cm: 6110007
 UHF Antenna: 6110004
CLM302
Cellular add-on (2G/3G)
8300045
CLM412
Cellular add-on (4G)
8300049
GSM501
Cellular add-on (2G)
8300040
GSM512
Cellular add-on (3G)
8300043
Wireless
5
5
Frecuencias: 143: 433.92Mhz, 187:868.95Mhz
