18
baud rate to the corresponding baud rate again after response data sending finished.
5． set measuring result sending frequency：（ Successful response 0x800E，Failure response 0x800D）
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8001
0xXX00
0
0x00
X
Default frequency is sending 10 times measuring result in each second actively. When the
command is received successfully, change the frequency according to parameter PARA1.
XX = 0x0A : 10Hz
XX = 0x09 : 9Hz
XX = 0x08 : 8Hz
………
XX = 0x01 : 1Hz
XX = 0x00 : send measuring result passively, at this time you can achieve the measuring
result via the command “read measuring result”.
6．Read measurement results:
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8002
0x0000
0
0x00
X
When initiative sending frequency is set as 0, achieve the measurement results: via this
command.
Please refer to note 1 about the returned data analysis.
7．Zero command：（ successful response 0x800E，failure response 0x800D）
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8003
0x0000
0
0x00
X
Sensor starts zero device after sending this command.
8．Tare command：（ successful response 0x800E，failure response 0x800D）
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8004
0x0000
0
0x00
X
Sensor starts tare device after sending this command.
9．Start or stop preset tare device：（ successful response 0x800E，failure response 0x800D）
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8005
Tare
0
0x00
X
Sensor starts or stop preset tare device after sending this command.
The range of tare is 0~ the maximum tare value allowed.
When tare is 0, it will stop preset tare device. When tare is not 0, it will start preset tare
device.
10． Change measuring unit：（ successful response 0x800E，failure response 0x800D）
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8006
0xXX00
0
0x00
X
The default unit is kg when power on, when command is received successfully, change
the unit according to the parameter PARA1.
XX = 0：standard unit（kg）
