19
XX = 1： standard unit（g）
XX＝6：British unit（pound）
XX＝7：British unit（ounce）
Note 1：
The sensor returned the measured results of data format:
1．Data
STX
ID
CMD
PARA
PGNO
LEN
SUM
0xAB
0x00000000
0x8002
0x8300
0xXXXX
0
0x00
X
When adopting 0x8002 command achieve measurement results， answering CMD is
0x8002.
When sensor is set for the certain frequency and sent measurement results automatically,
CMD is 0x8300.
PARA：the current temperature AD.
2．Data in data area
Flag
Mode
Unit
Decimal Digit
Net Value
Tare Value
Gross Value
0
1
2
3
4,5,6,7
8,9,10,11
12,13,14,15
Flag: Bit0: 0 means weight is unstable 1 means weight is stable
Bit1: 0 means weight is in its range. 1 means weight is beyond the range.
Bit2: 0 means have startup to zero. 1 mean haven‟t startup to zero.
Bit3: 0means the current weight is more than the minimum weighing range
1 means the current weight is less than the minimum weighing range
Bit4: 1 the current OP box is soft unlock 0 the current OP box is not soft unlock
Bit5: 1 the current OP box hardware is unlock 0 the current OP box hardware is not
unlock
Bit6: 1 the lowest order of the result is always zero. 0 the lowest order of the result maybe
not zero.
Bit7: retain
Mode: 0：It stands for net weight weighing mode, at this time, tare and gross weight
column not transmission.
1：It stands for tare weighing mode.
2：It stands for Pre-set tare weighing mode.
Unit：
0： "Gram",
1： "kg",
2： "Tonne",
13： "Ounce",
14： "Pound",
15： "Kilo pound (kip)",
Decimal digits
Each weight value occupies 4 bytes, high-order in the front, and low in the rear. The highest Bit is the
sign bit. For example:
Flag
Mode
Unit
Decimal Digit
Net Value
0x01
0x00
0x01
0x03
0x80,0x00,0x04,0xD2
