Amplifier Section| continuous power output (20 Hz to 20 kHz, 8 Ω) | 45 W + 45 W |
|---|---|
| continuous power output (20 Hz to 20 kHz, 4 Ω) | 65 W + 65 W |
| DIN continuous power output (1 kHz, 8 Ω) | 60 W + 60 W |
| DIN continuous power output (1 kHz, 4 Ω) | 90 W + 90 W |
| total harmonic distortion (20 Hz to 20 kHz, 20 W, 8 Ω) | 0.05 % |
| input sensitivity/impedance (PHONO MM) | 2.8 mV/50 kΩ |
| input sensitivity/impedance (CD, TUNER, LINE/SB, TAPE 1/CD-R/MD, TAPE 2 MONITOR) | 200 mV/50 kΩ |
| PHONO (MM) overload level (1 kHz, T.H.D. 0.1 %) | 150 mV |
| output level/impedance (TAPE 1/CD-R/MD, TAPE 2 MONITOR) | 200 mV/1 kΩ |
| frequency response (PHONO MM) | 20 Hz to 20 kHz ± 0.5 dB |
| frequency response (CD, TUNER, LINE/SB, TAPE 1/CD-R/MD, TAPE 2 MONITOR) | 5 Hz to 100 kHz +0-3 dB |
| tone control (BASS) | ± 8 dB (100 Hz) |
| tone control (TREBLE) | ± 8 dB (10 kHz) |
| loudness contour (volume control set at – 30 dB position) | + 5 dB (100 Hz)/ + 3 dB (10 kHz) |
| signal-to-noise ratio (PHONO MM, 5 mV input) | 86 dB |
| signal-to-noise ratio (CD, TUNER, LINE/SB, TAPE 1/CD-R/MD, TAPE 2 MONITOR) | 106 dB |
| signal-to-noise ratio (DIN, continuous power/ 50 mW, PHONO MM) | 71 dB/ 67 dB |
| signal-to-noise ratio (DIN, continuous power/ 50 mW, CD, TUNER, LINE/SB, TAPE 1/CD-R/MD, TAPE 2 MONITOR) | 95 dB/ 71 dB |
Power Supply| power requirements | AC 220 - 230 V, 50/60 Hz |
|---|---|
| power consumption | 160 W |
| power consumption in standby mode | 1 W |
| AC outlet switched | 100 W |
Weight and Dimensions| dimensions (including knobs and other protruding parts) | 420 (W) x 335 (D) x 128 (H) mm |
|---|---|
| weight (without package) | 6.9 kg |
