Pioneer DJM-400 User Manual

DJM-400
65
5678
56
7
8
C
D
F
A
B
E
6. ADJUSTMENT
• There is no information to be shown in this chapter.
OTHERS
9P CABLE HOLDER 51048-0900
J801 JUMPER WIRE 9P D20PDY0910E
JA800,JA801 MIC JACK DKN1248
E
VRSW ASSY
SEMICONDUCTORS
IC901-IC903 BA4560F
IC904,IC905 TC74HC4052AF
Q933 2SA1576A
Q901-Q907 2SB1197K
Q916,Q918,Q920,Q922,Q924 2SD2114K
Q926,Q928,Q930 2SD2114K
D934-D936,D940-D947 1SS355
D901-D903 NKR131S
D904,D911,D918,D928-D933 SLI-343URCW(RST)
D905,D906,D912,D913 SLI-343YCW(RST)
D919,D920,D925-D927 SLI-343YCW(RST)
D937,D938,D948,D949 SLI-343YCW(RST)
D907-D910,D914-D917 TLGE68TG(NP)
D921-D924 TLGE68TG(NP)
SWITCHES AND RELAYS
S902-S912,S915,S916 DSG1079
S914 DSG1098
S913 DSG1099
S901 DSH1058
CAPACITORS
C941-C946 CEJQ100M50
C940,C947 CEJQ101M10
C901-C903,C906-C911,C915 CFTNA334J50
C917-C920 CFTNA334J50
C923-C930,C932-C935 CKSRYB103K50
C904,C905,C912-C914,C916 CKSRYB104K50
C921,C922,C931,C936-C939 CKSRYB104K50
C948 CKSRYB104K50
RESISTORS
R901,R906,R911,R915 RN1/16SE1202D
VR901,VR902 DCS1091
VR905,VR906,VR908-VR913 DCS1092
VR907,VR914 DCS1093
VR903,VR904 DCS1094
Other Resistors RS1/16S###J
OTHERS
12P CABLE HOLDER 51048-1200
CN902 FFC CONNECTOR 12P 52492-1220
CN901,CN903 FFC CONNECTOR 36P 52492-3620
F
CHRV ASSY
SWITCHES AND RELAYS
S1201,S1202 DSK1033
Mark No. Description Part No.
OTHERS
12P CABLE HOLDER 51048-1200
J1201 JUMPER WIRE 12P D20PDD1205E
LEVER SW STAY DNF1740
SCREW CMZ26P050FTB
G
FADER ASSY
SEMICONDUCTORS
D1103,D1104,D1106-D1109 1SS355
D1101,D1102 SLI-343YCW(RST)
SWITCHES AND RELAYS
S1101 ASH1037
S1102,S1103 DSG1079
RESISTORS
VR1101,VR1102 DCV1010
Other Resistors RS1/16S###J
OTHERS
CN1101 FFC CONNECTOR 12P 52492-1220
J1102 SMALL CONNECTOR PG06MR-E07
FADER STAY DNF1746
SCREW PMH20P040FTC
H
CFVR ASSY
SEMICONDUCTORS
D2001,D2002 1SS355
RESISTORS
VR2101 DCV1006
OTHERS
CN2102 MT CONNECTOR 6P 173979-6
I
TRANS ASSY
SEMICONDUCTORS
>
D209,D210 1SR154-400
>
D200-D203 RB160L-40
CAPACITORS
C200-C205 CKSRYB473K50
OTHERS
>
J2 CONNECTOR ASSY DKP3744
CN202 8P PCB CONNECTOR S8B-XH-A-1
Mark No. Description Part No.

Pioneer DJM-400 Specifications

General

Channels	2
Weight	3.2 kg
A/D, D/A Converter	24-bit
Frequency Response	20 Hz to 20 kHz
Total Harmonic Distortion	0.007% or less
Inputs	PHONO
Outputs	MASTER OUT x 1, HEADPHONE MONITOR OUT x 1
Effects	Delay, Echo, Flanger, Roll
Crossfader	Yes
Power Supply	AC 50/60 Hz
EQ	3-band EQ per channel (-26 dB to +6 dB)
Signal-to-Noise Ratio	97 dB (LINE)
