SAFETY
INSTRUCTIONS
READ INSTRUCTIONS
All the safety and
operatihg instructions should be
read
before the
appliance is operated.
RETAIN
INSTRUCTIONS
-
The
operating instruc-
tions
should be
retained for luture relerence.
HEED
WARNING
-
All warnings
on the appliance
and in the
operdting
instructions
should be adhered
to.
FOLLOW
INSTRUCTIONS
-
All
operating and use
inslructions
should be
followed.
WATER AND MOISTURE The
appliance should
not be
used near
water
-
for
example, near a
bathtub, washbowl, kitchen
sink,
laundry
tub, in a
wet basement, or near a swimming
pool,
etc.
LOCATION
-
The appliance should be installed
in a
stable location.
WALL
OR CEILING MOUNTING
-
The
appliance
should not be mounted to a wall or
ceiling.
VENTILATION
The appliance should be
situated so
that its location
or
position
does not interfere with
its
proper
ventilation. For example. the appliance
should not be situated
on a
bed, sota, rug,
or
similar surtace that may block the venlilation
open-
ings;
or,
placed
in a built-in installation, such as a
bookcase
or cabinet that may impede the flow of
air through the ventilation
openings.
HEAT
The appliance should be sitoated
away
from
heat sources
such as
radiators,
heat registers,
stoves,
or other appliances
(including
ampliliers)
that
produce
heat.
POWER
SOURCES
-
The appliance
should be con
nected
to a
power
supply only of the type describ-
ed
in
the operating instructions or as marked
on the
appliance.
POWER-CORD
PROTECTION
-
Power-supply
cords
should be routed
so that they are not likely to be
walked
on or
pinched
by items
placed
upon
or
against
them,
paying panicular
attention
to cords
at
plugs,
convenience receptacles,
and
the
point
where they
exit
from
the appliance.
POLARIZATION
-
lf
your purchased product
is
pro-
vided
with a
polarized power plug,
please
read
the
following
instructions. This
product
is
equ;pped
with a
polarized
alternating current line
plug
(a
plug
having one blade wider
than the other). This
plug
will lit into
the
power
outlet only one way. This is a
satety
feature.
lJ
you
are
unabie
to
inseft
the
plug
tully into
the outlet,
try
reversing
the
plug.
lJ the
plug
should still fail
to
fit,
contact
your
electrician
to replace
your
obsolete outlet. Do not defeat
the
sa{ety
purpose
of the
polarized
plug.
CLEANING
-
The
appliance should be
cleaned only
with a
polishing
cloth or a soft dry
cloth.
Never
clean with furnature wax,
benzine, insecticides
or
other volatile liquids
since they may corrode the
cabinel.
POWER
LINES
-
An outdoor antenna should be
located
away trom
power
lines.
NONUSE PERIODS
The
power
cord ot the ap-
pliance
should
be unplugged from
the
oullel
when
left unused for a long
period
of time.
OBJECT AND LIOUID ENTRY
-
Care should be
taken so that objects do not fall
and
liquids are not
spilled into the enclosure
through
openings.
DAMAGE REOUIRING
SERVICE
The
appliance
should
be seruiced
by
Pioneer
authorized setuice
center
or
qualified
service
personnel
when:
.
The
power-supply
cord
or
the
plug
has been
damaged; or
.
Objects have
lallen,
or liquid has been spilled into
the
appliance;
or
.
The appliance has been
exposed
to rain; or
.
The appliance does
not appear to operate
normally
or exhibits
a marked
change in
performance;
or
.
The appliance has been
dropped; or
the enclosure
damaged.
SERVICING
-
The user should
not
attempt to seruice
the appliance beyond
that
described in the
operating
instruclions.
For
all other
seaicing,
con-
tact the nearest Pioneer authorized setuice center.
OUTDOOR
ANTENNA
GROUNDING
-
lf an
outside antenna is
connected to the antenna
lerminal,
be sure the
antenna system
is
grounded
so as to
provide
some
protection
against voltage
surges and built
up static
charges.
ln
the U.S.A. section
810 of the National Elec-
trical Code, ANSI/NEPA
No.
70-1S4,
pro-
vides information with
respect to
proper
grounding
of the mast and
supporting struc-
ture,
grounding
ol the lead-in wi.e to an anten-
na discharge unit,
size of
grounding
conduc
tors, location
of antenna-discharge unit,
con
nection to
grounding
electrodes,
and
re-
quirements
lor
the
grounding
electrode. See
Fis. A.
a) Use No.
10 AWG
(5.3
mm?)
copper, No,8
AWG
(8.4
mm,)
aluminum,
No. 17
AWG
(1.0
mm'?) copper-
clad steel, bronze
wire,
or
larger
as
ground
wire.
b) Secure antenna lead-in and
ground
wires to
house
with
stand-off insulators spaced
from 4 {eet
(1.22
meters) to
6 feet
(1.83
meters) apaft.
ci
Mount
antenna
discharge
unit as closely as
possible
to
where lead in enters house.
d) Use
jumper
wire
not
smaller
than No.6
AwG
(13.3
mm'l)
copper or equivalent
when
separate antenna-ground
ing
electrode
is used.
CFOUND NG
ELECTROOE
SYSI€M
re
I
nreoo'
mera wsrer
orFl
FIG.A
IMPORTANT
1
CAUTION
The
lightning flash
with arrowhead,
within
an
equilateral triangle,
is intended
to alen the user
of the
presence
of uninsulated
"dangerous
voltage"
within the
product's
enclosure
that may be o{ sufficient
magnitude
to constitute
a risk
of electric shock to
persons.
CAUTIONI
TO PREVENT THE NISK
OF ELECTRIC SHOCK, DO
NOT REMOVE
COVER
(OR
BACK).
NO
USER.
SERVICEABLE PARTS INSIDE, BEFER
SERVIC,
ING TO OUALIFIED SERVICE PERSONNEL.
The
exclamation
point
within an equilateral triangle is
intended
to aleit rhe
user of the
presence
of important
operating and maintenance
(seruicingi
instructions in
the literature
accompanying the
appliance.
IMPORTANT
2
lf the
apparatus is titted
with AC mains
power
ourler(s),
e€ REAR PANEL
FACILITIES for
conv€nisnt connec-
tion
of sdditional Hi-Fi
component(s), Mako all connec-
tions to the AC
outl€r(sl 8nd the signal terminals fi6t.
Connect the
plug
to ths wsll
sck€t
last,
make sure thal
the
pow€r
switch is oft. Disconnect
th€ wall
plug
when
th€
squipm€nt is not in
(regulsr)
ue, a,g. whan
on
vacation.
FOR USE IN
THE
UNITED
KINGDOM
The wires in this
mains lead
are colour€d
in sccordance
with th€ lollowing code:
Elue:
N€utral
Brown:
Live
As the
colouE of the wires in the mains l€ad
of
this
ap-
paratus
may not
corraspond with the coloured marking
id€ntifying
the tsrminals in
your plug proceed
as
follows:
The wire which
is colourod blue must be conntrted to
th€ torminal which is marked with
th€
l6nsr N
or col-
oursd black.
The
wir€ which is coloursd brown must be connecled to
th€
tsrminal which is marked with the l€tter L or col-
ourd red,
Equipmcnt sold in tho U.K. is not
euppliod
wlth a
powrr
plug.
