HTV-2
2
EXPLODED VIEWS AND PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
NOTES:
Mark No. Description Part No.
1 Corner Pad Assy BTM 261136
(SHA2105)
2 Corner Pad Assy TOP 261141
(SHA2106)
3 Card Board (SHB1069) 257845
4 Packing Case See Contrast table (2)
5 Poly. Bag (SHL1186) 235305
NSP 6 Coaded Label (SRM1069) 244126
(1) PACKING PARTS LIST
7 PACKING
(2) CONTRAST TABLE
HTV-2/KUXC and HTV-2/KCXC are constructed the same except for the following:
2 (2/2)
1 (2/2)
1 (1/2)
2 (1/2)
3
5
HTV-SW2
HTV-C2
4
6
Mark
KUXC type KCXC type
4 Packing Case (SHG2066) 254975 Not used
4 Packing Case (SHG2081) Not used 257870
Part No.
Remarks
Symbol and Description
No.
