Pioneer M-LA21 - Assembly Parts Lists

19
M-LA21
Mark No. Description Part No.
Mark No. Description Part No.
PRIMARY ASSY
SEMICONDUCTOR
D311 (RECTIFIER IN-4001B) 011-024001-000A
RELAY • SWITCH
RL301 (RELAY 9 OSA-SS-212DM) 128-090109-000A
SW301 (SLIDE SW VOLT.SELECTOR) 025-230041-000A
CAPACITORS
C315,C321 (CERAMIC CAP 0.01µF) 003-010320-250A
OTHERS
CN8 HEADER CTL 2 PINS 135-PHS020-020J
JP WIRE AWG22 BROWN 054-010150-010J
JP WIRE AWG22 ORANGE 054-010150-030J
JP WIRE AWG22 BLUE 054-010150-050J
JP WIRE AWG22 RED 054-010150-061J
JP WIRE AWG22 BLACK 054-010150-093J
JP WIRE AWG22 YELLOW 054-010150-100J
AC CONTACT TERMINAL 137-400001-000J
FUSE HOLDER 7900,HT 550-790000-000J
JACK ASSY
SEMICONDUCTORS
IC502,IC504 BA4558DX
Q502,Q515 DTA124ES
Q501,Q503,Q513 DTC124ES
Q504 2SA1015
Q511 DTC114ES
Q512 2SC1815
Q516-Q518 2SK246
D506,D509,D510,D511 1N4148
DZ504 MTZJ9.0C
DZ505 MTZJ12B
CAPACITORS
C541,C543 CKCYB101K50
C539,C546 CKCYF103Z50
C547,C548 (MYLAR CAP 5600pF) 004-056210-100
C549 (MYLAR CAP 3300pF) 004-033210-100
C556,C557 CKCYB102K50
C533,C558 CGCYF104Z25
EC544,EC545 CEJQ2R2M50
EC532,EC548 CEJQ101M16
EC535,EC536 CEJQ220M16
EC561,EC562 CEJQ470M16
EC531,EC533,EC534,EC537 CEJQ100M16
EC546,EC559,EC560 CEJQ100M16
EC529,EC530,EC541 CEJQ1R0M50
RESISTORS
All Resistors RD1/4PU J
OTHERS
CN3,CN4 HEADER CTL 7 PINS 135-PHS070-070J
CN22 HEADER CTL 8 PINS 135-PHS080-080J
CN2 HEADER CTL 11 PINS 135-PHS110-110J
JK501 PUSH TERMINAL BOARD 118-000134-003J
JK502 PIN JACK BOARD 118-020202-001J
JP WIRE AWG26 50MM R 051-675050-006J
JP WIRE AWG26 50MM B 051-675050-009J
CN23 HEDER MOLEX 4PINS 53 135-053259-040J
POWER METER ASSY
OTHERS
CN11 HSG PMT3-11A JST 136-11PMT3-200J
CN12 HSG PMT3-7A JST 136-07PMT3-200J
CN13 CONN PIN 6 PINS 050-060060-200J
CN16 CONN PIN 3 PINS 050-030060-200J
LED ASSY
SEMICONDUCTORS
LED502,LED503 (LED-R-3MM&-S-STP)110-033040-013A
LED501 (LED-BL-3MM&-S-&&&) 110-033162-003A
RESISTORS
All Resistors RD1/4PU J
HP JACK ASSY
SWITCH
SW501 (PUSH BOTTON SWICH 2P2T) 021-022322-000A
OTHERS
JK503 HEADPHONE JACK ST 116-008020-000
D
C
6. ADJUSTMENT
There is no information to be shown in this chapter.
