90
9-25
PC mode 94 95 96 97 98
Signal name HDTV-W
Definition 1920*1080Hz
Dot clock frequency (MHz) 74.250
H frequency (kHz) 33.750
V frequency (Hz) 60.000
29.629 H total (uS)
(dots) 2200
25.859 H display period (uS)
(dots)
1920
1.185 H front porch (uS)
(dots) 88
0.592 H sync pulse width (uS)
(dots)
44
1.993 H back porch (uS)
(dots) 148
7.582 V total (mS)
(line) 563
16.000 V display period (mS)
(line)
540
0.040 V front porch (mS)
(line) 3
0.148 V sync pulse width (mS)
(line)
5
0.444 V back porch (mS)
(line) 15
H sync polarity Pos
V sync polarity Pos
Scan type Interlaced
NOT USED
Remarks HDCP
*HDCP : High-bandwidth Digital Content Protection
