1. CONTRAST OF MISCELLANEOUS PARTS
1.1 CONTRAST TABLE
• CONTRAST TABLE
PDP-425CMX/LUC5, PDP-427CMX/LUC and PDP-42MXE20/TYVP5 are constructed the same except for the fol-
lowing:
jpfy
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 56 ⋅ 10
1
561 ........................................................ RD1/4PU
5 6 1
J
47k 47 ⋅ 10
3
473 ........................................................ RD1/4PU
4 7 3
J
0.5 R50 ..................................................................................... RN2H
R 5 0
K
1 1R0 ..................................................................................... RS1P
1 R 0
K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k 562 ⋅ 10
1
5621 ...................................................... RN1/4PC
5 6 2 1
F
Ref. No.
Mark Symbol and Description
Rart No.
Remarks
PDP-425CMX
/LUC5
PDP-427CMX
/LUC
PDP-42MXE20
/TYVP5
PCB ASSEMBLIES
NSP
1..MAIN ASSY
AWV2285 AWV2424
AWV2425
17- 1
2..MAIN ASSY AWW1100 AWW1234
AWW1235
17- 2
2..VSIF ASSY AWW1101 AWW1244 AWW1245
NSP
1..SUB ASSY
AWV2287 AWV2427 AWV2427
19- 1 2..SENB ASSY AWW1102 AWW1217 AWW1217
15- 4
2..SENC ASSY AWW1103 AWW1218 AWW1218
19- 3 2..SEND ASSY AWW1104 AWW1219 AWW1219
15- 1 2..AUDIO ASSY AWW1105 AWW1237 AWW1237
15- 2 2..COMMSLOT ASSY AWW1106 AWW1221 AWW1221
15- 3 2..COMMSLOT IF ASSY AWW1107 AWW1222 AWW1222
13- 1 2..KEY ASSY AWW1108 AWW1223 AWW1223
13- 2 2..LED2 ASSY AWW1109 AWW1224 AWW1224
21- 4 42 Y DRIVE ASSY AWV2251 AWV2334 AWV2334
23- 5 MD DIGITAL ASSY AWV2254 AWV2345 AWV2345
PACKING SECTION
11- 1 > Power Cord ADG1215 ADG1215 Not used
11-15
Operating Instructions (English, French, Japanese) ARD1070 ARD1075 Not used
11-15
Operating Instructions (English/French/German Not used Not used ARE1466
/Italian/ Dutch/ Spanish/ Chinese)
11-17
Operating Instructions (7L)(CD-ROM) Not used Not used ARU1002
11-18
Caution Sheet ARM1201 Not used Not used
11- 6
Speed Clamp AEC2051 AEC1908 AEC1908
11-21 NSP Warranty Card ARY1146 ARY1146 Not used
11-21 NSP Warranty Card (EU) Not used Not used ARY1149
11-22 NSP Warranty Card ARY1146 ARY1166 Not used
11-23
NSP Polyethyene Bag AHG-195 AHG-195 Not used
11-35
Upper Carton AHD3418 AHD3559 AHD3560
11-37
Plasma Caution Sheet ARM1147 ARM1147 Not used
11-38
Image Caution Sheet ARM1220 ARM1220 Not used
