Pioneer PDP-4300 Service Manual

3
1
234
1
2
3
4
C
D
F
A
B
E
PDP-4300
5
3
(No.2)
3
(No.2)
6
1
2
7
•
VIDEO SLOT US Parts List
Mark No. Description Part No.
1 VIDEO SLOT US Assy AWV1907
2 Video Terminal Panel PRO ANG2540
3 Screw ABA1300
4 • • • • •
5 Screw BPZ30P080FZK
6 Rivet AEP-211
7 Sheet AMR3282
No.1
BMZ30P060FZK
Rear Case
EXPLODED VIEWS
÷
EXTERIOR SECTION
÷
VIDEO SLOT US ASSY
