PDP-4300
Mark No. Description Part No. Mark No. Description Part No.
C7323 CEAT4R7M50
C7304 CEATR47M50
C7327,C7331,C7338 CKSQYB105K10
C7303 CKSRYB103K50
C7328,C7332,C7336 CKSRYB104K16
C7334 CKSRYB223K50
C7301,C7306-C7315,C7317,C7322 CKSRYF104Z16
C7324-C7326,C7329,C7330,C7335 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
K7301-K7304 TEST PIN AKX9002
X7301 CRYSTAL RESONATOR ASS1152
(16.2MHz)
[DVI BLOCK] (AWV1906 Only)
SEMICONDUCTORS
IC7409 24LCS21A
IC7402-IC7408 TC74LCX541FT
IC7410 TC7WH04FU
IC7401 TFP201A
D7401 1SS184
D7402,D7404 1SS226
D7403 RD6.8MB
CAPACITORS
C7406,C7408,C7410,C7413,C7414 CCSRCH101J50
C7417,C7420,C7421,C7425-C7428 CCSRCH101J50
C7432,C7434 CCSRCH101J50
C7403 CEAT470M10
C7401,C7402,C7404,C7405,C7407 CKSRYF104Z16
C7409,C7411,C7412,C7415,C7416 CKSRYF104Z16
C7418,C7419,C7422-C7424 CKSRYF104Z16
C7429-C7431,C7433,C7435-C7438 CKSRYF104Z16
RESISTORS
R7412 RAB4C220J
R7401,R7402,R7408,R7409 RAB4C680J
R7413-R7416,R7423,R7429,R7432 RAB4C680J
R7438 RAB4C680J
R7417,R7418 RN1/16SE1001D
Other Resistors RS1/16S J
OTHERS
CN7402 24P DVI SOCKET AKP1216
[CONNECTOR BLOCK]
RESISTORS
R7430 RS1/16S101J
R7439, R7440 RS1/16S103J
R7433 RS1/16S182J
R7435 RS1/16S223J
R7434 RS1/16S332J
[VIDEO REG BLOCK]
SEMICONDUCTORS
IC7501 PQ05DZ11
IC7504 PQ3DZ13
IC7502 TA79L05F
FILTERS
F7501-F7515 EMI FILTER ATF1194
CAPACITORS
C7504,C7539 CEAT101M6R3
C7501,C7511 CEAT221M16
C7506,C7508,C7510,C7514,C7516 CEAT470M25
C7520,C7524,C7526,C7528,C7530 CEAT470M25
C7532,C7534,C7536,C7541,C7543 CEAT470M25
C7545 CEAT470M25
C7502,C7503,C7505,C7507,C7509 CKSRYF104Z16
C7512,C7513,C7515,C7517,C7519 CKSRYF104Z16
C7522,C7523,C7525,C7527,C7529 CKSRYF104Z16
C7531,C7533,C7535,C7537,C7538 CKSRYF104Z16
C7540,C7542,C7544 CKSRYF104Z16
RESISTORS
R7502 RS1MMF1R0J
R7519 RS1MMF4R7J
OTHERS
SCREW ABA1295
NYRON RIVET AEP-211
3004 PROTECTION SHEET AMR3282
HEXAGONAL HEAD SCREW BBA1051
SCREW BPZ30P080FZK
