Pioneer PDP-503PE

PDP-503PE, PDP-503PU
27
2.12 REAR SECTION
1 Rear Case (50P) ANE1598
2 Gascket A ANK1688
3 Screw AMZ30P060FZK
4 Screw TBZ40P080FZK
5 Cleaning Label AAX2751
NSP 6 Name Label (HD) See Contrast table (2)
7 Bolt Caution Label AAX2852
8 Terminal Display Label P AAX2858
9 Terminal Display Label L See Contrast table (2)
(1) REAR SECTION PARTS LIST
Mark No. Description Part No.
1
1
2
5
67
4
3 3 3 3
4
4
4
4
3
3 38 93
Bottom View
3 3
4
4
4
4
(2) CONTRAST TABLE
PDP-503PE/WYVI6 and PDP-503PU/KUC are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
PDP-503PE PDP-503PU
WYVI6 KUC
NSP 6
9
Name Label (HD)
Terminal Display Label L
AAL2358
AAX2860
AAL2357
AAX2859
