Page #146 background imageLoading...
Page #146 background image
PDP-508XG
146
1234
1 234
C
D
F
A
B
E
11. PCB PARTS LIST
CONTRAST OF PCB ASSEMBLIES
MAIN ASSY
AWV2465 and AWV2466 are constructed the same except for the following:
TANSHI ASSY
AWW1258 and AWW1256 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
Ω
47k
Ω
0.5
Ω
1
Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k
Ω
RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
>
1..MAIN ASSY (508XG type) AWV2465
>
1..MAIN ASSY (508XDA type) AWV2465
>
1..MAIN ASSY (508XC type) AWV2466
NSP 1..FUKUGO ASSY (508XG type) AWV2491
NSP 1..FUKUGO ASSY (508XDA type) AWV2489
NSP 1..FUKUGO ASSY (508XC type) AWV2491
2..TANSHI ASSY(508XG type) AWW1258
2..TANSHI ASSY(508XDA type) AWW1256
2..TANSHI ASSY(508XC type) AWW1258
2..SIDE IO ASSY AWW1259
2..50XGA LED ASSY AWW1280
2..50LED&RLS&IR ASSY AWW1281
2..SIDE KEY ASSY AWW1286
Mark No. Description Part No.
Mark Symbol and Description AWV2465 AWV2466 Remarks
R4020 RS1/16SS0R0J Not used
R4021 Not used RS1/16SS0R0J
R8313 RS1/16SS103J Not used
R8330 Not used RS1/16SS103J
Mark Symbol and Description AWW1258 AWW1256 Remarks
L9081 Chip Coil Not used BTH1103
JA9081 Vert Opt.link Out Not used AKN1082
R8891, R9052 Not used RS1/16S0R0J
R8894, R9054 RS1/16S0R0J Not used
C9081 Not used CKSRYB105K10
