PDP-508XG
36
1234
1 234
C
D
F
A
B
E
5. SERVICE FACTORY MODE
SERVICE FACTORY MODE of PDP-508XG/DLFT,PDP-508XDA/YP and PDP-508XC/WA5 is the same as PDP-5080XA/WYV5 except for the following:
5.1 OUTLINE OF THE SERVICE FACTORY MODE
5.1.1 REMOTE CONTROL CODE IN SERVICE FACTORY MODE
Operations during Service Factory mode are described here.
Remote Control Keys Basic Functions Remarks
MUTINGSwitching the main items. Shifting to the next main item (top).
j (DOWN)
Switching the subtitled items. Shifting downward to the next subtitiled item.
i (UP)
Switching the subtitled items. Shifting upward to the next upper layer.
k (LEFT)
Decreasing the adjustment value. Decreasing the adjustment value.
l (RIGHT)
Increasing the adjustment value. Increasing the adjustment value.
ENTER/SET Switching the layers. Shifting downward or upward to the next lower or upper layer.
INPUT Selecting INPUT. Shifting the INPUT to the next function.
INPUTxx Selecting INPUT. Switching the INPUT to xx. (xx=1 to 6 etc)
CH+/P+ Increasing the channel num
ber.
CH-/P- Decreasing the channel number.
Numeric Keys Function: TV Function: TV (previously selected channel number is selected)
POWER Power OFF. Turning the power off.
FACTORY
Factory OFF (Factory mode) In Factory mode, turning Factory mode off.
Factory ON (Non-Factory mode). In Non-Factory mode, turn Fuctory mode on.
HOME MENU Menu ON. In Factory mode, turn Factory mode off.
VOLUME+ Volume UP. Increasing 10 the adjustment value. (PANEL FACTORY)
VOLUME- Volume DOWN. Decreasing 10 the adjustment value. (PANEL FACTORY)
DRIVE OFF (Note1) Drive Mode OFF. Turning Drive mode off.
IN
TEGRATOR INTEGRATOR MENU ON. Enter INTEGRATOR MODE.
(Note 1) When ten seconds have passed since the [DRIVE OFF] key was pressed at the standby, it becomes invalid.
Please press [POWER] key from the [DRIVE OFF] key pressing within ten seconds when you do power supply ON while
driven OFF.
PDP service
remote control
PDP-508XG
PDP-508XDA PDP-508XC
To Next Page
