< No. 8 Subcategory Information on "Failure in
IIC communication of MTB side" >
Value Shutdown Factor Remarks (Operation)
1Tuner 1
2 MSP/MAP Shutdown
Shutdown
3AV Switch Shutdown
4 RGB Switch Shutdown
5 VDEC Shutdown
6 VDEC-SDRAM Shutdown
7 AD/PLL Shutdown
8 HDMI Shutdown
< No. 7 Subcategory Information on "Failure in 3-wire
serial communication of Main microcomputer" >
Value Shutdown Factor Remarks (Operation)
1
Communication error of IF
microcomputer
Shutdown
2
Communication error of
sequence processor
Shutdown
< No. 10 Subcategory Information on "Abnormally in
FAN" >
Value Shutdown Factor Remarks (Operation)
1FAN 1Shutdown
2FAN 2 (FHD only) Shutdown
< No. 12 Subcategory Information on "Failure in
Digital Tuner" > (PDP-508XDA only)
Value Shutdown Factor Remarks (Operation)
1DTV starting failure Communication stop
2DTV communication error Shutdown
< No. 13 Subcategory Information on "Failure in
Power supply at MTB side" >
Value Shutdown Factor Remarks (Operation)
1 RST 2 Shutdown
2 RST 4 Shutdown
