Notes : The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
For PCB ASSEMBLIES, Refer to “5. SCHEMATIC DIAGRAM” , “6. PCB CONNECTION DIAGRAM" and “7. PCB PARTS LIST”.
*1 : DTV TUNER BOARD has no service parts.
>
NSP
Power Cord Not used ADG1244 Not used Not used
>
NSP
Power Cord Not used ADG1246 Not used Not used
>
NSP
Power Cord Assy Not used AWX1095 Not used Not used
PAL RF Cable (30cm) Not used Not used ADF1036 Not used
Caution Card (PC) Not used Not used Not used ARM1302
REAR SECTION
NSP P163-17 Name Label AAL3005 AAL3011 AAL3012 AAL3014
P163-19 Bolt Caution Label (E) AAX3533
AAX3533 AAX3533 AAX3550
P163-20 Label A AAX3480 AAX3485 AAX3484 AAX3485
P163-21 Label B50 AAX3543 AAX3500 AAX3520 AAX3500
P163-22 Label C AAX3504 AAX3507 AAX3521 AAX3507
P163-23 Terminal Panel B ANC2454 ANC2456 ANC2456 ANC2456
P163-28 Input Cover Label E AAX3510 AAX3511 AAX3511 AAX3511
P163-38 Screw BPZ30P080FTB Not used Not used Not used
Destination Label O Not used AAX3446 Not used Not used No. 2
NSP CCC S&E Label Not used Not used Not used DRW2310 No. 3
Screw Not used BBZ30P060FTB BBZ30P060FTB BBZ30P060FTB No. 15
FRONT SECTION
P165-12 Front Case Assy AMB3025 AMB3026 AMB3027 AMB3026
MULTI BASE SECTION
P173-7 Flexible Cable (J217) ADD1494 Not used Not used Not used
P173-20 POD Cover AMR3542 Not used Not used Not used
P173-21 Multi Base Assy ANA2103 ANA2103 ANA2104 ANA2103
P173-22 Terminal Panel A ANC2441 ANC2445 ANC2446 ANC2445
12P Housing Wire (J131) Not used Not used ADX3549 Not used No. 4
Flexible Cable (J219) Not used Not used ADD1450 Not used No. 5
Flexible Cable (J220) Not used Not used ADD1497 Not used No. 6
NSP Bottom Can Not used Not used XNA1005 Not used No. 7
Top Can Not used Not used XNG1002 Not used No. 8
Screw Not used Not used ABZ30P060FTC Not used No. 9
Screw Not used Not used BBZ30P060FTB Not used No. 10
Screw Not used Not used PMB30P080FNI Not used No. 11
Gasket N Not used Not used ANK1776 Not used No. 12
Frontend Holder G Not used ANG3120 Not used ANG3120 No. 13
Screw Not used AMZ30P060FTC Not used AMZ30P060FTC No. 14
Mark No. Symbol and Description
PDP-508XD
/WYV5
PDP-508XG
/DLFT
PDP-508XDA
/YP
PDP-508XC
/WA5
Remarks
