12
RS-232C Adjustment
Command
434CMX
505CMX
Command
425CMX
Command
607CMX
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
FAN
FCM
++
Maximizes fan rotation control.

FCA
++
Automates fan rotation control.

––FCU
Sets integrator’s fan rotation control maximum to apply a
brightness

New, and effective
only on the 507CMX
OSD
DIN OSDS00
+
Sets OSD display to OFF.

DIY OSDS01
+
Sets OSD display to ON.

– OSSS01
+
Displays expanded OSD.

– OSSS02
+
Displays contracted OSD.

– OSAS01
+
Sets the OSD display angle to horizontal.

– OSAS02
+
Sets the OSD display angle to vertical.

FRONT INDICATOR
LEN LESS00
+
Sets the FRONT INDICATOR to OFF.

LEY LESS01
+
Sets the FRONT INDICATOR to ON.

COLOR MODE
CM1 CLMS00
+
Sets the COLOR MODE to NORMAL.

CM2 CLMS01
+
Sets the COLOR MODE to STUDIO.

UNDER SCAN
USCS00
++
Sets the UNDERSCAN setting to OFF.

USCS01
++
Sets the UNDERSCAN setting to ON.

USC
++
Displays the present set value of UNDERSCAN.
IMAGE PROCESS
–
IPR
+
Obtains the present IMAGE PROCESS setting.
–
IPRS01
+
Sets the IMAGE PROCESS to NORMAL.

–
IPRS02
+
Sets the IMAGE PROCESS to PURE.

–
IPRS03
+
Sets the IMAGE PROCESS to MONOTONE.

–
IPRS04
+
Sets the IMAGE PROCESS to HIGH CONTRAST.

––IPRS05 Sets the IMAGE PROCESS to BLUE ONLY.

New
FRC
FRC
++
Displays the present set value of FRC.
– FRCS00
+
Sets the FRC to OFF.

FRCS01
++
Sets the FRC to ON.

Note 1
SEAMLESS INPUT SWITCH
–
SLSS00
+
Sets the SEAMLESS INPUT SWITCH mode to OFF.

–
SLSS01
+
Sets the SEAMLESS INPUT SWITCH mode to ON.

–
SL1S01
+
Sets the SEAMLESS SW SELECT 1 to INPUT1.

–
SL1S02
+
Sets the SEAMLESS SW SELECT 1 to INPUT2.

–
SL1S03
+
Sets the SEAMLESS SW SELECT 1 to INPUT3.

–
SL1S04
+
Sets the SEAMLESS SW SELECT 1 to INPUT4.

–
SL1S05
+
Sets the SEAMLESS SW SELECT 1 to INPUT5.

–
SL2S01
+
Sets the SEAMLESS SW SELECT 2 to INPUT1.

–
SL2S02
+
Sets the SEAMLESS SW SELECT 2 to INPUT2.

–
SL2S03
+
Sets the SEAMLESS SW SELECT 2 to INPUT3.

–
SL2S04
+
Sets the SEAMLESS SW SELECT 2 to INPUT4.

–
SL2S05
+
Sets the SEAMLESS SW SELECT 2 to INPUT5.

MIRROR
MIRS00
++
Sets mirror mode to OFF (normal display).

MIRS01
++
Performs left-right reversal with MIRROR MODE.

MIRS02
++
Performs up-down reversal with MIRROR MODE.

MIRS03
++
Performs up-down left-right reversal with MIRROR MODE.

MULTI SCREEN
–
PTRS00
+
Sets sub screen translucence to OFF (0%).

–
PTRS01
+
Sets sub screen translucence to 10 %.

–
PTRS02
+
Sets sub screen translucence to 20 %.

–
PTRS03
+
Sets sub screen translucence to 30 %.

–
PTRS04
+
Sets sub screen translucence to 40 %.

–
PTRS05
+
Sets sub screen translucence to 50 %.

–
PTRS06
+
Sets sub screen translucence to 60 %.

–
PTRS07
+
Sets sub screen translucence to 70 %.

–
PTRS08
+
Sets sub screen translucence to 80 %.

Note 1: The operation differs between the PDP-434CMX/PDP-505CMX and PDP-425CMX/PDP-607CMX
