Pioneer PDP-607CMX - Page 18

18
RS-232C Adjustment
5) <QSS> Obtaining SETUP information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QSS (fixed)
3 COLOR TEMP. 1 Byte 1: LOW 2: MID LOW 3: MIDDLE 4: MID HIGH
5: HIGH Note 1)
4 POWER MGT. 1 Byte 0: OFF 1: ON
5 AUTO POWER OFF 1 Byte 0: DISABLE 1: ENABLE
6 DNR 1 Byte 0: OFF 1: LOW 2: MIDDLE 3: HIGH Note 1)
7 MPEG NR 1 Byte 0: OFF 1: LOW 2: MIDDLE 3: HIGH Note 1)
8 CTI 1 Byte 0: OFF 1: ON Note 1)
9 PURECINEMA 1 Byte 0: OFF 1: ON Note 1)
10 COLOR DECODING 1 Byte 1: RGB 2: COMP1 3: COMP2 Note 1)
11 COLOR SYSTEM 1 Byte 1: AUTO 2: NTSC 3: PAL 4: SECAM 5: 4.43NTSC
6: PAL M 7: PAL N Note 1)
12 DVI SET UP (PLUG/PLAY) 1 Byte 1: PC 2: VIDEO Note 1)
13 DVI SET UP (BLACK LEVEL) 1 Byte 1: LOW 2: HIGH Note 1)
14 BRT.ENHANCE 1 Byte 0: OFF 1: ON Note 1)
15 SUB VOLUME 2 Byte 00 to 20
16 Main input function 3 Byte Same as item 9 of QST commands
17 Main screen size information 1 Byte Same as item 11 of QST commands
18 Check sum 2 Byte
19 ETX 1 Byte 03hex
Note 1) In the case of set data that cannot be output because of the type of input signal, dummy data is output.
6) <QSO> Obtaining menu integrator/OPTION information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QSO (fixed)
3 ENERGY SAVE 1 Byte 0: STANDARD 1: MODE1 2: MODE2 3: MODE3
4: AUTO 5: MUTE
4 PROGRAM/REPEAT timer 1 Byte 0: OFF 1: PROGRAM 2: REPEAT
5 SCREEN MANAGEMENT (ORBITER) 1 Byte 0: OFF 1: MODE1 2: MODE2 3: MODE3
6 SCREEN MANAGEMENT (SOFT FOCUS) 1 Byte 0: OFF 1: 1 2: 2 3: 3 4: 4
7 AUTO SETUP MODE 1 Byte 0: INACTIVE 1: ACTIVE
8 AUTO FUNCTION 1 Byte 0: OFF 1: INPUT1 2: INPUT4
9 PIP DETECT 1 Byte 0: INACTIVE 1: ACTIVE
10 SPLIT FREEZE 1 Byte 0: OFF 1: SIDE BY SIDE 2: PIP
11 SCREEN MASK 1 Byte 0: OFF 2: INVERSE 3: WHITE 4: RED 5: GREEN 6: BLUE
7: YELLOW
12 SIDE MASK R-LEVEL 3 Byte 000 to 255
13 SIDE MASK G-LEVEL 3 Byte 000 to 255
14 SIDE MASK B-LEVEL 3 Byte 000 to 255
15 VIDEO WALL (MODE) 1 Byte 0: OFF 1: 1 screen 2: 4 screens (2 x 2) 3: 9 screens (3 x 3)
4: 16 screens (4 x 4) 5: 25 screens (5 x 5)
16 VIDEO WALL (POSITION) 2 Byte 01 to 56
17 VIDEO WALL (TYPE) 1 Byte 0: NORMAL 1: ADJUSTED
18 VIDEO WALL (POWER ON DELAY) 1 Byte 0: OFF 1: ON 2: MODE1 3: MODE2
19 VIDEO WALL (ABL LINK) 1 Byte 0: OFF 1: ON
20 Spare (dummy) 1 Byte * (FIX)
21 FAN CONTROL 1 Byte 1: AUTO 2: MAX
22 OSD DISPLAY 1 Byte 0: OFF 1: ON
23 OSD SIZE 1 Byte 0: LARGE 1: SMALL
24 OSD ANGLE 1 Byte 0: H 1: V
25 FRONT INDICATOR 1 Byte 0: OFF 1: ON
26 COLOR MODE 1 Byte 1: NORMAL 2: STUDIO
