Pioneer PE6000 Series User Manual

PE6000 User Manual Function Code Tables
75
Function
Code
Parameter Name Setting Range Default Property
AC-12 AO1 target voltage 1 0.500–4.000 V
Factory
corrected
☆
AC-13 AO1 measured voltage 1 0.500–4.000 V
Factory
corrected
☆
AC-14 AO1 target voltage 2 6.000–9.999 V
Factory
corrected
☆
AC-15 AO1 measured voltage 2 6.000–9.999 V
Factory
corrected
☆
4.2 Monitoring Parameters
Table 4.2 Monitoring Parameter Table
Function
Code
Parameter Name Min. Unit
Communication
Address
Group U0: Standard Monitoring Parameters
U0-00 Running frequency (Hz) 0.01 Hz 7000H
U0-01 Set frequency (Hz) 0.01 Hz 7001H
U0-02 Bus voltage 0.1 V 7002H
U0-03 Output voltage 1 V 7003H
U0-04 Output current 0.01 A 7004H
U0-05 Output power 0.1 kW 7005H
U0-06 Output torque (%) 0.1% 7006H
U0-07 DI state 1 7007H
U0-08 DO state 1 7008H
U0-09 AI1 voltage (V) 0.01 V 7009H
U0-10 AI2 voltage (V) 0.01 V 700AH
U0-12 Count value 1 700CH
U0-13 Length value 1 700DH
U0-14 Load speed 1 700EH
U0-15 PID setting 1 700FH
U0-16 PID feedback 1 7010H
U0-17 PLC stage 1 7011H
