81
SC-57
5
6 7 8
5
6 7 8
A
B
C
D
E
F
(1) EXTERIOR SECTION PARTS LIST
(2) CONTRAST TABLE
SC-57/UXJCB, SC-55/UXJCB and SC-1526-K/CUXJ are constructed the same except for the following:
Mark No. Description Part No.
1 MIC HP GUARD ASSY AWX9803
2 FAN CONNECT ASSY AWX9804
3 IR REG ASSY AWX9806
4 B DIODE ASSY AWX9808
NSP 5 FFC GUARD2 ASSY AWX9812
6 DISPLAY BRIDGE ASSY AWX9815
7 F-IN BRIDGE ASSY AWX9816
8 USB RECT ASSY AWX9821
> 9 Power Transformer See Contrast table (2)
> 10 Fuse (FU13, FU14 : 1A) REK1142
> 11
Fuse (FU11, FU12, FU15 : 1.25A)
REK1143
> 12 Fuse (FU10 : 4A) REK1149
13 15P FFC (J0002) ADD7745
14 39P FFC (J0015) ADD7746
15 4P Housing ASSY (Y0020) ADX7755
16 4P Housing ASSY (Y0025) ADX7757
17 2P Housing ASSY (Y0024) ADX7758
18 3P Housing ASSY (Y0023) ADX7759
19 3P Housing ASSY ADX7766
20 7P Housing ASSY (Y0022) ADX7767
21 Cord Clamper /HL AEC7653
22 Cushion 11 x 7 AED7092
23 PCB Mold (PP) AMR2533
24 Insulator AMR7198
NSP 25 Panel Stay 85 (MTL) ANG7684
26 Push Rivet AEC7071
27 Top Beam 85 (MTL) ANG7726
28 Lisence Label ARW7419
29 Bonnet 85 (BOX) AZN8050
NSP 30 Mini Clamp VEC1597
31 Screw (Steel) ABA1011
32 Screw 3 x 10B (Steel) ABA1193
33 Screw 4 x 12 (FE) ABA7109
34 Cup Screw 3 x 8 FCC ABA7149
35 Screw BBT30P080FCC
36 Screw BBZ30P060FCC
37 Screw BCZ40P060FTB
38 Screw IBP30P090FCC
39 Screw IBZ30P180FTC
40 Screw BBZ30P080FTB
41 Toothed Lock Washer WH40FNI
NSP 42 Binder (BK-1) ZCA-BK1
Mark
No. Description Part No.
Mark No. Symbol and Description
SC-57/
UXJCB
SC-55/
UXJCB
SC-1526-K/
CUXJ
> 9 Power Transformer ATS7447 ATS7438 ATS7438
To Next Page
