Pioneer SC-LX75 Service Manual

86
SC-57
1
2 3 4
A
B
C
D
E
F
1
2 3 4
9.5 FRONT SECTION
Note ∗1: Please pay attention not to hurt Panel Base 55U when you remove the Front Panel.
Note ∗2: Please tape up at four (4) places to protect
Panel Base 55U as shown on the
photograph when you remove the Front
Panel.
Note ∗3: Double Side Tape (10mm x 30mm) affixing position on Front Panel
Left side Right side
DIGITAL MAIN ASSY
JA905
DISPLAY BRIDGE ASSY
CN7652
USB RECT
ASSY CN3652
DIGITAL MAIN
ASSY CN1501
Accessory of
Panel Base
Accessory of
Panel Base
F-IN BRIDGE ASSY
CN7763
∗1
∗2
∗2
∗2
∗2
∗3
N
M
K
J
C
L
Accessory of
Panel Base
Nitto H9012
Nitto H9012
Nitto H9012
Nitto H9012
B
B
Double side
tape 20mm
Double side
tape
Double side
tape 30mm
Double side
tape 20mm
A
A
CONTACT SIDE
NON-CONTACT
SIDE
Inside
Center line
+0mm
-1.5mm
