Pioneer sc-lx86 User Manual

17
Connecting your equipment .........................................................................................................18
Rear panel ......................................................................................................................................18
Determining the speakers’ application ........................................................................................19
Placing the speakers ...................................................................................................................... 22
Connecting the speakers ...............................................................................................................22
Installing your speaker system .....................................................................................................24
About the audio connection .........................................................................................................29
About the video converter ...........................................................................................................29
About HDMI ...................................................................................................................................30
Connecting your TV and playback components .........................................................................30
Connecting an HDD/DVD recorder, BD recorder and other video sources ............................... 33
Connecting a satellite/cable receiver or other set-top box ........................................................34
Connecting other audio components ..........................................................................................35
Connecting additional amplifiers .................................................................................................35
Connecting the multichannel analog inputs ............................................................................... 36
Connecting AM/FM antennas .......................................................................................................36
MULTI-ZONE setup ........................................................................................................................37
Connecting to the network through LAN interface ...................................................................40
Connecting optional Bluetooth ADAPTER ...................................................................................40
Connecting an iPod........................................................................................................................40
Connecting a USB device ..............................................................................................................41
Connecting an MHL-compatible device ....................................................................................... 41
Connecting an HDMI-equipped component to the front panel input ...................................... 41
Using a USB cable to connect to a PC ...........................................................................................42
Connecting to a wireless LAN .......................................................................................................42
Connecting an IR receiver .............................................................................................................42
Switching components on and off using the 12 volt trigger .....................................................43
Plugging in the receiver ................................................................................................................43
Connecting your equipment

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
