Pioneer sc-lx86 User Manual

33
03
Connecting your equipment
Connecting an HDD/DVD recorder, BD recorder and other video
sources
This receiver has audio/video inputs suitable for connecting analog or digital video devices, including HDD/DVD
recorders and BD recorders.
When you set up the receiver you’ll need to tell the receiver which input you connected the recorder to (see also
The Input Setup menu on page 47).
BD IN
LAN
(
10/100
)
OUT 2OUT 1
DC OUTPUT
for WIRELESS LAN
(
OUTPUT
5 V
0.6 A MAX
)
OPTICALCOAXIAL
ASSIGNABLE ASSIGNABLE
VIDEO
AUDIO
(CONTROL)
DVR/BDR
INOUT
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
4
(
VIDEO
)
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
IN
6
IN
7
OUT
BD IN
LAN
(
10/100
)
OUT 2OUT 1
DC OUTPUT
for WIRELESS LAN
(
OUTPUT
5 V
0.6 A MAX
)
OPTICALCOAXIAL
ASSIGNABLEASSIGNABLE
VIDEO
AUDIO
(CONTROL)
DVR/BDR
INOUT
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
4
(
VIDEO
)
IN
1
(
TV
)
IN
2
(
DVR/BDR
)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
IN
6
IN
7
OUT
HDD/DVD recorder, BD recorder, etc.
VIDEO
VIDEO OUT
VIDEO
VIDEO IN
DIGITAL OUT
COAXIAL
ANALOG
RL
AUDIO OUT
ANALOG
RL
AUDIO IN
OPTICAL
Select one
! In order to record, you must connect the analog audio cables (the digital connection is for playback only) (page
78).
! If your HDD/DVD recorder, BD recorder, etc., is equipped with an HDMI output terminal, we recommend con-
necting it to the receiver’s HDMI DVR/BDR IN terminal. When doing so, also connect the receiver and TV by
HDMI (see Connecting using HDMI on page 30).
BD IN
OUT 2 OUT 1
(CONTROL)
IN
1
(
DVD
)
IN
2
(
SAT/CBL
)
IN
3
(
DVR/BDR
)
IN
4
(
VIDEO
)
IN
6
IN
7
HDMI IN
HDMI OUT
HDMI/DVI-compatible monitorHDD/DVD recorder, BD recorder, etc.

Pioneer sc-lx86 Specifications

General

Receiver type	Surround
Output impedance	6 Ω
Speaker selector	A+B
Audio output channels	9.1 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	8
AC (power) in	Yes
Remote (IR) input	1
Composite video in	4
Digital audio optical in	2
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Supported radio bands	AM, FM
Optical drive included	No
Display	-
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS 96/24, DTS-ES, DTS-HD, DTS-HD Master Audio
Apple docking compatibility	iPad, iPhone, iPod
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, ITA, RUS
Graphical user interface (GUI) language	English, French, German, Italian, Russian, Spanish
AC input voltage	230-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	370 W
THX-certified	THX Select2 Plus
Cables included	AC
