Additional information09
40
En
Video Section
• Input (Sensitivity/Impedance)
DVR/VCR, DVD/BD, TV/SAT. . . . . . . 1 Vp-p/75
Ω
• Output (Level/Impedance)
DVR/VCR, MONITOR OUT . . . . . . . . 1 Vp-p/75
Ω
• Frequency response
DVR/VCR, DVD/BD,
TV/SAT
MONITOR . . . . . 5 Hz to 7 MHz dB
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . 55 dB
Crosstalk . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 dB
Component video section
• Input (Sensitivity/Impedance)
DVD/BD, TV/SAT, DVR/VCR. . . . . . . 1 Vp-p/75
Ω
• Output (Level/Impedance)
MONITOR OUT . . . . . . . . . . . . . . . . . 1 Vp-p/75
Ω
• Frequency response
DVD/BD, TV/SAT,
DVR/VCR
MONITOR . . 5 Hz to 40 MHz dB
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . 60 dB
FM Tuner Section
Frequency Range . . . . . . . 87.5 MHz to 108 MHz
Usable Sensitivity . . . . . . . . Mono: 13.2 dBf, IHF
(1.3 µV/75
Ω
)
50 dB Quieting Sensitivity . . . . . Mono: 20.2 dBf
Stereo: 38.6 dBf
Signal-to-Noise Ratio . . Mono: 73 dB (at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Distortion. . . . . . . . . . . . . . . Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity. . . 60 dB (400 kHz)
Stereo Separation . . . . . . . . . . . . . . 40 dB (1 kHz)
Frequency Response . . . . . . . . . 30 Hz to 15 kHz
(±1 dB)
Antenna Input (DIN) . . . . . . . . .75
Ω
unbalanced
AM Tuner Section
Frequency Range . . . . . . . . 530 kHz to 1700 kHz
Sensitivity (IHF, Loop antenna) . . . . . . 350 µV/m
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . 50 dB
Antenna . . . . . . . . . . . . . . . . . . . . . .Loop antenna
Miscellaneous
Power requirements . . . . . . . . . . AC 120 V/60 Hz
Power consumption . . . . . . . . . . . . . . . . . .280 W
In standby. . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 W
Dimensions
. . . . . 420 mm (W) x 158 mm (H) x 352.5 mm (D)
16
9
/
16
in. (W) x 6
1
/
4
in. (H) x 13
7
/
8
in. (D)
Weight (without package). . . . 7.9 kg (17 lb 4 oz)
Furnished Parts
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Dry cell batteries (AA size IEC R6)
. . . . . . . . . .2
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . .1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . .1
These operating instructions
Note
• Specifications and the design are subject
to possible modifications without notice,
due to improvements.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe
off dust and dirt.
• When the surface is dirty, wipe with a soft
cloth dipped in some neutral cleanser
diluted five or six times with water, and
wrung out well, and then wipe again with a
dry cloth. Do not use furniture wax or
cleansers.
• Never use thinners, benzine, insecticide
sprays or other chemicals on or near this
unit, since these will corrode the surface.
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which
requires repair will be charged for even during the
warranty period.
K041_En
