Pioneer XR-A330 Service Manual

XR-A660, XR-A330
19
A
B
C
D
5
678
5
6
7
8
Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST".
DISPLAY ASSY
(XR-A660/KUCXJ : XWZ3092)
(XR-A660/YPWXJ : XWZ3110)
(XR-A330/KUCXJ : XWZ3058)
(XR-A330/YPWXJ : XWZ3047)
I
SECONDARY
ASSY
(XR-A660 : XWZ3084)
(XR-A330 : XWZ3046)
F
PRIMARY ASSY
(KUCXJ Type: XWZ3059)
(YPWXJ Type: XWZ3051)
G
SUB TRANS ASSY
(KUCXJ Type: XWZ3060)
(YPWXJ Type: XWZ3052)
H
AEK7071
XR-A660 ONLY
XR-A660 ONLY
KUCXJ
TYPE
ONLY
XR-A660 ONLY
YPWXJ TYPE
KUCXJ TYPE
