XR-VS400
5
AF ASSY
F
F
XWZ3313 and AWU7788 are constructed the same except for the following :
CONTRAST OF PCB ASSEMBLIES
DISPLAY ASSY
F
I
AWU7799 and XWZ3315 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3315 AWU7799
IC5501 PDC063B PDC082A
D5594 1SS133 Not used
D5601-D5608, D5621 SLP6118C51H SLR-343MC(NPQ)
D5610, D5611, D5615, D5616, D5622, D5904 SLP3118C51H SLR-343MC(NPQ)
D5612, D5614 SLP6118C51H SLR-343DC(NPQ)
D5617 SLP6118C51H Not used
D5618 SLP3118C51H Not used
D5619, D5620, D5903 SLP9118C51H SLR-343VC(NPQ)
D5902 SLP7118C51H SLR-343PC(KLM)
S5911, S5913, S5915–S5921, S5923–S5929, S5931–S5940 XSG3001 ASG1051
R5501 RS1/16S105J Not used
R5502 RS1/16S0R0J RS1/16S331J
R9901, R9902 Not used RS1/16S101J
X5501 CERAMIC RESONATOR (10MHz) DSS1048 ASS7034
Mark Symbol and Description
Part No.
Remarks
XWZ3313 AWU7788
C44 Not used CEAT222M25
C3001, C3002, C3858 Not used CCSRCH101J50
C3011, C3012 Not used CEATR47M50
C3041, C3042 CEAT2R2M50 Not used
C3046 CEJA100M50 CEJQ100M50
C5697 Not used CKSRYB102K50
R2000 Not used RS1/16S0R0J
R3333, R3334 RD1/4LMF100J RD1/2LMF100J
R3994 Not used RD1/4PU221J
CN3331 SPEAKER TERMINAL XKE3004 AKE7018
Notes : For PCB ASSEMBLIES, Refer to “PCB PARTS LIST”, “2. SCHEMATIC DIAGRAM” and “3. PCB CONNECTION DIAGRAM”.
Ref. No. Mark Symbol and Description
Part No.
Remarks
XXA3017 AXA7107
P9- 3 NSP $M SERVO VCD ASSY XWX3018 Not used
P9- 3 3CD ASSY Not used AWP7035
AXA7107 and XXA3017 are constructed the same except for the following :
CONTRAST OF $M MECHA. VCD
PRIMARY ASSY
F
H
AWU7965 and XWZ3291 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3291 AWU7965
L1 LINE FILTER ATF7018 Not used
To Next Page
