XR-VS400
6
Mark No. Description Part No. Mark No. Description Part No.
÷
PCB PARTS LIST
F
B
3CD ASSY
SEMICONDUCTORS
IC1001 BA033FP
IC1701 CL680T-D1
IC1851 LC324265BT-25P
IC1801 LC895199K-ND2
IC1301 M56788AFP
IC1756 MSM514260C-60TS
IC1401 PCM1742KE
IC1501 PD5693A
IC1751 PEB001A
IC1551 STA013
IC1101 TA2151FN
IC1451 TC74HCT157AF
IC1202 TC7SH08FU
IC1776 TC7W14FU
IC1771 TC7WU04FU
IC1201 TC9495F
Q1101 2SA1036K
Q1351, Q1353 2SB1132
Q1551, Q1553, Q1701 2SC2412K
Q1352, Q1354 2SD1664
Q1433, Q1434 2SD2114K
Q1431, Q1432 DTA124EK
Q1355, Q1356 DTC143EK
D1351–D1354 1SS355
D1431, D1432 DAN202K
COILS AND FILTERS
L1712 LCTB1R8K2125
L1711 LCTB2R7K2125
L1102, L1202, L1206 QTL1013
CHIP SOLID INDUCTOR
L1713, L1721 CHIP BEADS VTL1072
L1756 CHIP BEADS VTL1074
L1781 CHIP BEADS VTL1084
L1777, L9260, L9262 CHIP BEADS VTL1086
L1271, L1771, L1776 CHIP BEADS VTL1087
CAPACITORS
C1119, C1541–C1544, C1568, C1569 CCSRCH101J50
C1712, C1734, C1781 CCSRCH101J50
C1773, C1774 CCSRCH120J50
C1201 CCSRCH150J50
C1307, C1714 CCSRCH151J50
C1202 CCSRCH220J50
C1711, C9753 CCSRCH221J50
C1126 CCSRCH271J50
C1713 CCSRCH331J50
C1210, C1303, C1720, C1735, C1737 CCSRCH470J50
C1117 CCSRCH560J50
C1519, C1520 CCSRCH821J50
C1116 CCSRCJ3R0C50
C1401, C1402, C1405, C1417, C1418 CEV100M16
C1001, C1008, C1101, C1102, C1108 CEV101M16
C1205, C1222, C1224, C1231, C1321 CEV101M16
C1351, C1502 CEV101M16
C1002, C1115, C1236, C1552 CEV101M4
C1783, C1784 CEV221M4
C1133 CEV3R3M50
C1203, C1228 CEV470M6R3
C1242, C1261, C1771, C1776 CKSRYB102K50
C1009, C1103, C1107, C1114, C1204 CKSRYB103K50
C1206, C1207, C1212, C1214, C1223 CKSRYB103K50
C1225–C1227, C1230, C1232, C1239 CKSRYB103K50
C1406, C1503–C1506, C1556, C1756 CKSRYB103K50
C1808–C1811, C1813, C1821, C9001 CKSRYB103K50
C9201, C9203, C9441, C9501, C9551 CKSRYB103K50
C9701, C9703, C9751, C9801, C9851 CKSRYB103K50
C1003, C1104, C1110, C1111, C1131 CKSRYB104K16
C1245, C1260, C1271, C1322, C1325 CKSRYB104K16
C1403, C1404, C1451, C1553–C1555 CKSRYB104K16
C1703–C1706, C1710, C1716–C1718 CKSRYB104K16
C1721–C1724, C1731, C1733, C1736 CKSRYB104K16
C1753, C1758, C1759, C1772, C1777 CKSRYB104K16
C1782, C1803–C1807, C1812 CKSRYB104K16
C1852, C1853 CKSRYB104K16
C1725 CKSRYB152K50
C1211 CKSRYB153K25
C1213 CKSRYB222K50
C1112, C1113 CKSRYB224K10
C1215 CKSRYB333K16
C1237, C1291, C1557 CKSRYB471K50
C1558 CKSRYB472K50
C1216, C1217 CKSRYB473K16
C1311, C1319 CKSRYB682K50
RESISTORS
R1540, R1541, R1819, R1820 RAB4C0R0J
R1219, R1520 RAB4C221J
R1546, R1813–R1816 RAB4C473J
R1318 RS1/16S1202F
R1319 RS1/16S2202F
R1317 RS1/16S2702F
Other Resistors RS1/16S&&&J
OTHERS
CN1201 FFC CONNECTOR 16P AKN7028
CN1102 CONNECTOR 3P B3P-SHF-1AA
JA1201 OPTICAL LINK OUT GP1FA550TZ
CN1301 CONNECTOR SFW13R-1ST-TFB
CN1101 CONNECTOR SFW15R-1ST-TFB
JA1701 1P PIN JACK VKB1063
CN1501 8P CONNECTOR VKN1300
X1551 CERAMIC RESONATOR ASS7037
(10MHz)
X1501 CERAMIC RESONATOR DSS1098
(16MHz)
X1201 CRYSTAL RESONATOR VSS1084
(16.9344MHz)
X1751 CRYSTAL RESONATOR VSS1086
(27.0MHz)
X1801 CRYSTAL RESONATOR VSS1130
(33.86MHz)
