Piper PA-28 Cherokee 140 User Manual

PartsNeededToCompleteKit
ÿ 1RudderServo(minimum100oz.torque)andmountinghardware(suchasHitecHS645MG)
ÿ 1LargeRudderServoArm
ÿ 1ElevatorServo(minimum100oz.torque)andmountinghardware(suchasHitecHS645M G)
ÿ 2AileronServos(minimum70oz.torque)andmountinghardware(suchasHitecHS645MG)
ÿ 2FlapServos(minimum50oz.torque)andmountinghardware
ÿ 1NoseWheelServo(minimum50oztorque)andmountinghardware
ÿ 1ThrottleServo(minimum40oz.torque)andmountinghardware
ÿ 124inchServoExtension(Elevator)
ÿ 224inchServoExtensions(Ailerons)
ÿ 26inchServoExtensions(ThrottleandNoseWheel)
ÿ 3“Y”ServoExtensions(Flaps,Ailerons,Rudder/NoseWheel)
ÿ 1–3inches1/8inchHeatShrinkTubing
ÿ 1–3inches5/8inchHeatShrinkTubing
ÿ 1Engine40ccto50ccgas(recommendedDLE55)
ÿ 1–IgnitionBatt ery(asperyourenginemanufacturer’sinstructions)
ÿ 1–Propeller2022inch(weused22x10)
ÿ 1RadioTransmitter(minimum5channels)
ÿ 1Receiver
ÿ 1ReceiverBattery
ÿ 1SwitchHarness
ÿ 13½inchAluminumSpinner
Notes:Loctiteeverythingt hatdoesn’tnee dto beremovedoradjustedoften.
TestFitallTNuts(BlindNuts)toallowboltstobeeasilystartedbyhandandavoidcrossthreads.AstripedTNutcanbe
difficulttoreplace.
Page1
