CHART 2107. BLOWER SYSTEM WIRE COLOR CODES
AIRCRAFT
MOTOR WIRES WIRES
YY1S062
Pin ESB- Universal Aircraft Pin
Nos. Elect. Company Harness Nos.
Ground Plug 2 Brown AC26A 2 Receptacle
Low Speed Plug 1 Yellow Black 1 Receptacle
Medium Speed Receptacle 2 Red White 2 Plug
High Speed Receptacle 1 Orange Red 1 Plug
—END—
21-50-48
Page 21-47
Revised: December 21, 1981
1G22
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
