For replacement parts, call our customer service department at 888-804-7455, 8
a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday. NOTE: Not all parts
are replaceable.
WARNING: When the grill is not in use, the regulator must hang on the side of the firebox.
20
21
Part Description Part #
1 Thermometer 1
2 Thermometer Bezel 1
3 Grill Lid 1
4 Lid Bumper 2
5 Lid Handle Bezel 2
6 Lid Handle Insulating Spacer 2
7 Lid Handle 1
8 Knob 2
9 Bezel 2
10 Control Panel 1
11 Valve and Manifold Assembly 1
12 Regulator 1
13 Main Burner 2
14 Match Light Tool 1
15 Grease Tray 1
16 Control Panel Bracket 2
17 Foldable Leg 4
18 Leg Hinge Screw 4
19 Hex Screw 4
20 Fire Box 1
21 Lid Hinge Screw 2
22 Cooking Grate 1
23 Flame Tamer 2
02
03
04
05
04
05
06
06
22
23
23
19
13
13
14
16
16
17
17
17
17
18
18
18
18
19
19
19
20
21
09
09
10
11
12
15or15-A
08
