Pit Boss PB3BGD2 - Page 2

3
EN
ENGLISH
  
MODEL ASSEMBLED (WxDxH) WEIGHT COOKING AREA HEAT INPUT

32
1,438  728  940  /
56.6  28.6  37.0 
52.7  /
116.2 
3,460  /
536.3 
10.5 
Part# Description
1 Firebox (x1)
2 Hot Plate (x1)
3 Hot Plate Leg Screws (x4)
4 Grease Cup (x1)
5 Lid Support (x1)
6 Lid Handle Bezel (x2)
7 Lid Handle (x1)
8 Cart Front Panel (x1)
9 Cart Back Panel (x1)
10 Cart Side Panel - Left (x1)
11 Cart Side Panel - Right (x1)
12 Side Shelf - Left (x1)
13 Side Shelf - Right (x1)
14 Paper Towel Hook (x1)
15 Side Shelf Bracket - Left (x2)
16 Side Shelf Bracket - Right (x2)
17 Support Leg for Caster - Front (x1)
18 Support Leg for Caster - Back (x1)
19 Support Leg for Wheel - Front (x1)
20 Support Leg for Wheel - Back (x1)
21 Bottle Opener (x1)
22 Locking Caster (x2)
23 Wheel (x2)
24 Bottom Shelf (x1)
A Screw (x37)
B Washer (x16)
C Locking Washer (x16)
D Screw (x4)
E Wheel Cotter Pin (x2)
F Wheel Washer (x2)
G Wheel Axle Pin (x2)
H Battery (x1)
NOTE: Due to ongoing product development, parts are subject to change without notice. Contact
Customer Care if parts are missing when assembling the unit.
  
  
 
1
2
5
4
6
7
9
8
10
3
11
14
12
13
17
18
19
20
15
21
22
24
23
16
