Teacher Parts Setup
Left Gripper Gear Arm
Right Gripper Gear Arm
12X – Pivot Washer
11X – Self-Tapping Screw
Self-Tapping Screw
Servo Hub Adapter
Gripper Pincer
Gripper Plate
4X – Gripper Pivot Arm
Servo Mount
9
