pitsco tetrix prime Setup Guide

Standard Servo Assembly
Locate the standard servo kit, which can be identified using the label attached to the servo. You will
need the standard servo with screw, the servo mount with screws, a servo shaft hub, and a setscrew.
You will also need Phillips-head and socket-head screwdrivers. Assemble the standard servo as
indicated in the illustrations.
Standard servo motors are used for proportional rotation and for grippers, steering, and positioning.
Servo Mount
Standard Servo
Self-Tapping Screw
Servo Shaft Hub
Servo Horn Screw
Quantity Part
1 Standard Servo
1 Servo Mount
1 Setscrew
1 Servo Shaft Hub
Setscrew
13
