Structural Elements
TETRIX PRIME Hardware Components
Beams
The beams are named by the number
of small holes on one side of the beam.
Do not select beams by counting
the larger holes (see right).
15-Hole Square Beam 40207
13-Hole Square Beam 40206
8-Hole Square Beam 40205
7-Hole Square Beam 40204
6-Hole Square Beam 40203
5-Hole Square Beam 40202
4-Hole Square Beam 40201
To identify TETRIX PRIME Square Beams, count the small holes. The
example above is a 4-hole square beam.
1:1 scale
1 2 3 4
48 Building and Coding the PULSE CodeeBot
