Straight Block Beam Connector 40216
90-Degree Beam Bracket 40208
60-Degree Beam Bracket 40209
Tee Beam Bracket 40210
Quick Rivet Connector 40219
Thumbscrew 40323
90-Degree Cross Block Connector 40217
Beam Attachment Hub 40228
TIP: These two parts, the straight block
beam connector and the 90-degree cross
block connector, are very close in appearance
and can be easily confused. Please double-
check that you are using the one the
directions call for.
Quick Rivet Peg 40220
Wing Nut 40221
Structural Elements
50 Building and Coding the PULSE CodeeBot
