Page 10 For technical questions, please call 1-888-866-5797. 68892
Part Description Qty
01a Hydraulic Pump 1
02 Link 1
03 Pin 1
04 R-Pin 5
05 Release Valve Spindle 1
06 Link 1
07 Pin 2
09 Pump Piston Spindle 1
10 Release Foot Pedal 1
11 Lift Foot Pedal 1
12 Bolt M6*16 8
13 Washer 6 17
14 Caster 2
15 Bolt M12*70 4
16 Washer 12 8
17 Bushing 4
18 Lifting Screws 2
20 Lock Washer 6 9
21 Nut M6 9
22 Locking Bar 1
23 Washer 10 6
25 Lock Washer 12 8
26 Nut M12 8
27 Spring 1
28 Bushing 4
Part Description Qty
29 Bolt M12*65 4
30 Nut M10 4
31 Lock Washer 10 4
32 Stop Plate 1
33 Bolt M10*25 4
34 Vise 1
35 Platform 1
36 Access Panel 1
37 Ramp 1
38 Front Lifting Arm 1
39 Rear Lifting Arm 1
40 Lifting Arm Spindle 1
41 Bolt M8*12 1
43 Washer 13.5 2
44 Front Wheel 2
47 Cotter Pin 2
48 T-Connector 1
49a Base Plate 1
53 Bolt M6*30 1
54 Set Screw M8*12 1
55 U-Clamp 2
56 Nut M8 8
57 Grease Fitting 7
58 Pump Shaft 2
59 Set Screw (M6*10) 2
Parts Lists and Assembly Diagrams
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Frame Parts List
