PLAN XP1M - Technical Specification; Features summary

X P 1 M I N S T A L L E R G U I D E
4
Technical Specification
Enclosure
Construction
Powder coated steel cabinet
Dimensions
320 x 260 x 95mm (H x W x D)
Weight
3.20 Kg
Power
Input
100 – 250v ~ 2.3A 50/60/440 Hz or DC 120-300v 1.5A
Output
Integral 12vDC PSU/Charger unit fused @ 3.15 Amps
Environmental
Operating Temp
0
o
C to +40
o
C
Storage
-10
o
C to +50
o
C
Humidity
10% to 80% (non-condensing relative humidity)
Interfaces
Communications
RS422/RS485/TCP-IP** WiFi*
Reader Interface
Wiegand or ‘Clock and Data’
Protection
Isolated communication, over voltage protection and
transient suppression on all inputs.
* Using appropriate plug-in module.
Features summary
2 card reader inputs (with RTE and Alarm Monitoring facility)
3 extended alarm inputs
50,000 Card holders *
2,000 Event Cyclical Transaction Memory
Fire Alarm override input (jumper configurable)
128 Time Profiles
Shut-down profiles
AES 128 bit encrypted communications
1 x General alarm relay output
Built-in PSU charger Option
TCP/IP LAN and WiFi wireless communications option
* Cardholder capacity may vary depending on card format configuration
