X P 1 M I N S T A L L E R G U I D E
5
Installation Procedure
XP1M Control Panel location
The control panel is supplied in a wall mounting enclosure. Care should be
taken to ensure that the mounting surface and the fixings used are appropriate
for the weight of the panel. The following additional notes and observations
should be considered when choosing a location for the unit.
1) The unit is not designed to be mounted externally unless it is fitted within
a suitably rated secondary enclosure.
2) Sufficient free space around the unit (approx 35mm) should be left clear
for the purpose of removing the outer doors.
3) The unit must be fitted in an upright orientation (hinges to the left).
4) Do not use the XP1M enclosure to house additional equipment (other
than devices specifically designed to be fitted inside the box).
The unit should always be mounted in an accessible location - ideally on the
secure side of the doors that are controlled by the panel.
Mounting
Remove and retain all packaging and documentation that was shipped with the
unit. The precise fixing methods will vary from application to application,
however, as a general guide
1) Before fitting the back-box to the wall, establish the preferred route for
cable access into the enclosure; the box is supplied with a number of
25mm holes to the rear and several 20mm knock-out’ access points to
the top, bottom and side walls. Use a hammer and punch to remove
any of ‘knock-outs and drill any additional holes that are required
before fixing the box to the wall.
2) There are four fixing holes in the rear of the enclosure. If necessary,
use the back-box as a template to mark the fixing holes on the wall -
note that the top two fixings are ‘key-holed to enable easier single
handed installation.
Connecting up
Mains Power
The XP1M controller unit can be supplied with an integral 13.8vDC
PSU/charger. This unit is fitted into the rear of the back-box and must be
powered from a continuous mains supply. Ideally the mains supply will be
isolated through a dedicated un-switched, fused spur. The length and type of
cable that is used to connect the charger unit to the mains supply should
Note: Always install at
least one manual access
override if a controller is
located within an area that
has no other means of entry
(i.e other than through a
controlled door).
