X P 1 M I N S T A L L E R G U I D E

Commissioning Procedure

Powering up the unit

Before applying mains power to the XP1M, make a final check that all

connections are made off and terminated correctly. It is important that these

checks are carried out at the panel and at the door location. Ensure that all

unused conductors and foil shielding is insulated and made ‘safe’ as necessary

to prevent short circuits when the panel is closed.

To initiate the first time power-up sequence apply mains power to the

PSU/charger. Check that the LED on the PSU is displaying Green and that

the “5vDC” and LED on the xP1M is illuminated. If the LEDs are on,

connect the stand-by batteries to the PSU charger.

For direct cabled applications ensure that the ‘Comms Select’ jumpers are set

for RS422. For alternate communications configurations such as WiFi or

Ethernet, please refer to the relevant paperwork.

Setting the station ID

If the XP1M is connected in a network to other PLAN400s or PLAN200s,

then each unit must be given a Station-ID in the range 01-16. To Set the

Station ID for this panel simply use the dip switches as indicated on the PCB

overlay.

The control panel is now ready to be tested on-line. Refer to the

software manual for further instruction.
